- Open Access
Using bispectral index and cerebral oximetry to guide hemodynamic therapy in high-risk surgical patients
Perioperative Medicine volume 2, Article number: 11 (2013)
High-risk surgery represents 12.5% of cases but contributes 80% of deaths in the elderly population. Reduction in morbidity and mortality by the use of intervention strategies could result in thousands of lives being saved and savings of up to £400m per annum in the UK. This has resulted in the drive towards goal-directed therapy and intraoperative flow optimization of high-risk surgical patients being advocated by authorities such as the National Institute of Health and Care Excellence and the Association of Anaesthetists of Great Britain and Ireland.
Conventional intraoperative monitoring gives little insight into the profound physiological changes occurring as a result of anesthesia and surgery. The build-up of an oxygen debt is associated with a poor outcome and strategies have been developed in the postoperative period to improve outcomes by repayment of this debt. New monitoring technologies such as minimally invasive cardiac output, depth of anesthesia and cerebral oximetry can minimize oxygen debt build-up. This has the potential to reduce complications and lessen the need for postoperative optimization in high-dependency areas.
Flow monitoring has thus emerged as essential during intraoperative monitoring in high-risk surgery. However, evidence suggests that current optimization strategies of deliberately increasing flow to meet predefined targets may not reduce mortality.
Could the addition of depth of anesthesia and cerebral and tissue oximetry monitoring produce a further improvement in outcomes?
Retrospective studies indicate a combination of excessive depth of anesthesia hypotension and low anesthesia requirement results in increased mortality and length of hospital stay.
Near infrared technology allows assessment and maintenance of cerebral and tissue oxygenation, a strategy, which has been associated with improved outcomes. The suggestion that the brain is an index organ for tissue oxygenation, especially in the elderly, indicates a role for this technology in the intraoperative period to assess the adequacy of oxygen delivery and reduce the build-up of an oxygen debt.
The aim of this article is to make the case for depth of anesthesia and cerebral oximetry alongside flow monitoring as a strategy for reducing oxygen debt during high-risk surgery and further improve outcomes in high-risk surgical patients.
Intraoperative hemodynamic optimization in high-risk surgical patients is becoming a gold standard in anesthetic practice in the UK . It is clear that the monitoring standards set by the Association of Anaesthetists of Great Britain and Ireland, that is, electrocardiography (ECG), pulse oximetry, end tidal carbon dioxide and non-invasive blood pressure, give little indication of the adequacy of oxygen delivery (DO2) to the patient during surgery . The build-up of an oxygen debt during high-risk surgery, which can lead to an increase of postoperative complications and mortality, was considered inevitable [3, 4]. Although repayment of the oxygen debt early in the postoperative period by goal-directed therapy (GDT) guided by sophisticated hemodynamic monitoring achieves beneficial outcomes [5, 6], little emphasis has been placed on the potential role of maintaining DO2 intraoperatively and limiting build-up of the oxygen debt.
Pulse oximetry and monitoring end tidal carbon dioxide concentration, together with invasive arterial and central venous monitoring, continue to be the linchpin of conventional monitoring that most anesthetists use today even for high-risk patients. Advanced hemodynamic intervention strategies to manage these patients are evident in only around 10% of patients . Based on the evidence that high-risk surgical procedures represent about 12.5% of the global volume of surgery carried out worldwide, this means that a realistic target of reduction in mortality from 10% in the control groups to 6% in the intervention groups could mean that potentially up to 800,000 lives could be saved by hemodynamic intervention strategies .
However, the situation may be changing as recent guidelines from the UK’s National Institute of Health and Care Excellence (NICE) have emphasized better outcomes and cost savings from hemodynamic monitoring by use of oesophageal Doppler monitoring (ODM) (Deltex Medical Group, Chichester, UK) [1, 9]. This has now been extended to include all flow monitoring technologies with recent guidelines published on the management of proximal femoral fractures by the Association of Anaesthetists of Great Britain and Ireland recommending that we should consider hemodynamic monitoring, depth of anesthesia (DOA) monitoring and the use of cerebral oximetry . A recent consensus statement from the Enhanced Recovery Partnership has also highlighted the importance of individualized goal- directed fluid therapy alongside the use of hemodynamic monitoring stating that ‘all Anaesthetists caring for patients undergoing intermediate or major surgery should have cardiac output measuring technologies immediately available and be trained to use them’ . NICE has now extended their guidance to include a recommendation for the use of depth of anesthesia monitoring in these high-risk (elderly) patients .
What about the role of combined monitoring?
In a review published in 2010 it was proposed that hemodynamic monitors combined with the use of depth of anesthesia and cerebral oximetry monitoring might further improve outcomes. Although there is limited evidence on the use of combined monitoring, the case for its use will be made .
It is possible to measure cerebral and tissue oxygenation (regional oxygen saturation, rSO2) by the use of near infrared technology (NIRS) . The Invos cerebral and tissue oximeter (Invos CTO, Covidien, CO, USA) was the first available for routine clinical use. Although there are now four main manufacturers employing this technology, opinions are still divided as to its place in routine anesthesia practice . Nevertheless, the cerebral and tissue oximeter has been proposed as providing an index of brain and tissue oxygenation. The proposition that the brain is an index organ  is based on the fact that significant falls in rSO2 predict poor outcomes (both cerebral and non-cerebral) in both cardiac [17, 18] and non-cardiac surgical patients . Significant rSO2 desaturation may occur in up to 30% of major non-cardiac surgical procedures in elderly patients  and is usually associated with blood loss . More importantly randomized controlled studies suggest that maintenance of rSO2 within 10% to 20% of baseline in these same patient groups reduces complications [16, 18]. Although the normal rSO2 in a fit young patient may be around 60% to 70%, representing a venous weighted measure of cerebral tissue oxygenation, values as low as 35% are sometimes seen in elderly patients presenting for surgery and may be a significant predictor of a poor outcome . A recent study suggests that rSO2 is a potentially important ‘biomarker to measure in heart failure patients and suggests that it may be a useful marker of target organ perfusion’ . What is most interesting is that this monitor provides an early warning system for picking up imbalances between cerebral oxygen supply and demand, specifically deficient cerebral oxygen delivery, and if placed over the forehead, acts as an indicator of ischemia in the watershed area of the brain – that area supplied by the middle and anterior cerebral arteries. Other monitors may not identify these abnormalities .
Thus, a pre-induction measure of rSO2 for an elective patient provides a starting point from which to measure cumulative oxygen desaturation and also acts as a predictor of the likelihood of intraoperative and postoperative complications.
Propositions concerning rSO2and oxygen debt
Oxygen debt can be assessed by measuring the difference in oxygen consumption (VO2) intraoperatively and comparing this value with that obtained in the immediate preoperative period . However, calculation of oxygen consumption requires pulmonary artery catheterization to determine the mixed venous oxygen content as well as thermodilution to measure cardiac output (CO) and cannot easily be employed routinely. An association exists between cumulative oxygen debt occurring during surgery and the immediate postoperative period with a poor outcome [3, 4]. These deleterious effects may be ameliorated by artificially increasing oxygen delivery to so-called goal-directed therapy (GDT) targets of 600 ml.min-1.m-2 using inotropes and fluids in the immediate postoperative period . However, such aggressive therapy may not be necessary if oxygen delivery can be maintained and oxygen debt minimized intraoperatively. The Shoemaker studies indicated that the build-up of oxygen debt was usually associated with reduced oxygen delivery intraoperatively. Thus maintaining oxygen delivery seems to be a logical strategy for the elective patient in order to minimize the build-up of an oxygen debt. In this context, the cerebral and tissue oximeter is arguably the best continuous non-invasive assessment of the adequacy of cerebral and tissue oxygenation, especially in elderly, elective surgical patients . If oxygen delivery is insufficient to supply enough oxygen for adequate cellular activity then rSO2 will fall (signifying increased oxygen extraction when supply is deficient) and should be corrected. A recent review also suggests that maintaining tissue oxygenation may improve outcomes .
Depth of anesthesia monitoring
Recent prospective, double-blinded studies have produced conflicting data on whether or not bispectral index (BIS) monitoring reduces patient awareness compared with other techniques such as close monitoring of end tidal anesthetic concentration in (say) the 0.7 to 1.3 minimal alveolar concentration (MAC) range. However, the trials are plagued with discrepancies in their protocols that render some of the results meaningless [24–26]. Nevertheless, what is clear is that patients who consistently have high BIS numbers are the ones most likely to be aware .
The recommended optimal ranges of maintenance BIS values are between 40 and 60 . Some evidence points to an association of excessive depth of anesthesia with poor outcomes especially in high-risk patients [29–31]. However, not all the data supports this hypothesis [32, 33]. Two studies carried out by analyzing retrospective data of two classes of patients who participated in the B-unaware study  showed conflicting results. A persistent BIS value below 45 led to a poor outcome in the cardiac surgical cohort . However, when this analysis was repeated for the non-cardiac surgical patients, no difference in outcomes was found . The proposed explanation for this paradox was ‘that BIS values lower than 45 are likely markers of systemic illness, poor cardiac function, or complicated intraoperative course,’ which explains the difference in outcomes for cardiac versus non-cardiac surgical patients .
This explanation must be vigorously challenged, as it seems naïve to assume that all patients have the same pharmaco-genetic make-up and if BIS is low then the concentration of anesthetic should be reduced. Our own data (Figure 1) show a fivefold variation in propofol requirements to maintain BIS in the 40 to 60 range (Figure 2) in a series of 103 high-risk, elderly patients. Without the correct use of depth of anesthesia monitoring it is clear that conventional population-based targets may lead to many patients being too deeply anesthetized whilst others will be too light.
Kertai et al. also state that ‘putting these data together, if the pharmacologically paralyzed patient were hypotensive and anesthetic was delivered at a clinically acceptable concentration with BIS values less than 45 (e.g. BIS of 39) the appropriate initial intervention might not be to decrease anesthesia. Instead, it might be preferable to treat hypotension with fluids, for example, or a drug such as norepinephrine or phenylephrine.’ Surely, if the patient were hypotensive with a low BIS (say 29, but you would need a BIS monitor to know this), would it not be more appropriate to reduce the depth of anesthesia first, rather than give more fluids and vasopressors? It is also common to have hypotensive elderly patients with a high BIS value and here we firstly need to vigorously treat the causes of hypotension and then deepen the anesthetic. How can we do that rationally without hemodynamic and BIS monitoring? A recent study supports a very close relationship between stroke volume and BIS level, which confirms depth of anesthesia as a potent cause of reduced cardiac output and oxygen delivery presumably resulting from propofol-induced venous tone reduction . Hence, for an elderly high-risk patient this could lead to a decrease in DO2 and even a build-up of oxygen debt . A conflict of rational management occurs here as, although a recent recommendation by expert authors suggests that depth of anesthesia monitoring should be used for total intravenous anesthesia, the same authors also advise that the concentration of anesthetic should not be adjusted to keep BIS within the target range .
Two recent reviews of the evidence for the effect of depth of anesthesia on outcomes call for large-scale prospective, randomized controlled trials to be urgently carried out to support or contradict the hypothesis that low BIS is associated with poor outcomes [37, 38]. Looking specifically at the incidence of delirium and cognition in the postoperative period in elderly patients, it would appear from the CODA trial that maintaining BIS in the 40 to 60 range significantly reduces the incidence of both these complications .
Retrospective analysis of a large anesthesia database at the Cleveland Clinic indicates an association between the cumulative time of being in a triple low state (low BIS <45, low minimal alveolar concentration, MAC < 0.8, and low mean arterial pressure, MAP < 75 mmHg) with a fourfold increase in 30-day mortality and increased length of hospital stay . The study emphasizes that these values are referenced on patients whose mean BIS, MAP and MAC values are outside one SD of their population mean values and not necessarily outside the range normally tolerated as clinically acceptable by most anesthetists. Interestingly, low BIS on its own was not a predictor of poor outcomes in this series, although in a high-risk patient a low BIS might be associated with low MAP and low MAC. Low MAP and BIS values in those receiving low anesthetic MAC may identify patients who are ‘unusually sensitive to anesthesia and at risk for complications’ confirmed. Their suggestion that ‘Inadequate cerebral perfusion is perhaps the most interesting putative cause of low BIS because it is potentially amenable to hemodynamic intervention, such as giving vasopressors or fluids to improve MAP and brain perfusion’ highlights the potential role of cerebral oximetry and flow monitoring alongside BIS in these patients . Figure 3 offers an explanation of how low BIS might be a potential cause of poor outcomes for high-risk/elderly patients but may be less predictive of outcomes in healthy patients. It should also be noted that although the emphasis has been on low BIS as a predictor of outcomes, a high BIS level may not only lead to awareness but also result in a lack of neuronal protection and lead to postoperative cognitive dysfunction , itself a cause of poor outcome .
It is usual anesthetic practice to maintain a patient’s MAP within 20% of the patient’s baseline value. A common response to a fall in MAP is to administer fluid, either crystalloids such as lactated Ringer’s or colloids such as gelatins or starch. Recent studies, however, have suggested that some patients receive too much fluid during major surgery and a fluid restriction or zero-balance strategy may lead to better outcomes [43, 44]. Most anesthetists still employ a maintenance fluid regime based originally on a paper published in 1961 by Shires et al., who were the first group to propagate what is now seen by many as a myth, that is, third-space loss. They suggested up to 15 ml.kg-1.hr-1 of lactated Ringer’s be administered to replace the extracellular fluid that had been presumed lost from the functional extracellular fluid volume (FECV). This regime may result in a patient receiving up to an equivalent of 10 days normal Na+ requirement (700 mmol) in the space of a four-hour operation. Evidence exists that excess fluid may damage the glycocalyx and thus exacerbate loss of FECV . This regimen may lead to poorer outcomes in comparison with GDT and restrictive regimens in colorectal surgery . Despite this evidence, even the most recent trials using hemodynamic optimization protocols continue to presume this third-space loss, with fluid administered in the control group, and the intervention group, often amounting to more than 10 ml.kg-1.hr-1 of lactated Ringer’s or Hartmann’s solution [48, 49]. A recent review of the evidence for third-space loss in surgery or following blood loss indicates that it does not occur  (see later).
Oesophageal Doppler monitoring
The potential for intraoperative hemodynamic monitoring to improve outcome has mainly been derived from work on oesophageal Doppler monitoring [12–14]. Unfortunately the three main studies on which the NICE guidelines were based used different end points in assessing the adequacy of optimal hemodynamics. Gan et al. and Noblett et al. used optimization of the flow-time corrected value maintained between 350 and 400 ms whilst Wakeling et al. used stroke volume maximization together with central venous pressure (CVP). The latter study led to the algorithm currently employed by Deltex (Deltex Medical PLC, Chichester, UK) the manufacturers of the Doppler monitor, which does not use CVP and flow-time corrected monitoring (Figure 4). When this algorithm was used in a recent study employing the ODM the intervention group actually had worse outcomes . In addition, using a Doppler monitor to maximize stroke volume (SV) does not seem to produce any benefits in outcomes when compared with a restrictive, zero-balance technique, despite achieving higher nominal cardiac output in the oesophageal Doppler intervention group .
Pulse contour and power analysis
There is surprisingly little data supporting the benefits of intraoperative (versus postoperative ) hemodynamic optimization using flow monitors, which analyze the arterial pressure waveform and convert it into flow. The LiDCOrapid monitor (LiDCO PLC, Cambridge, UK) analyses the whole arterial waveform and not just the systolic portion as do other devices and thus its estimates of stroke volume and cardiac output are less affected by changes in waveform morphology . Despite some confusion in the literature , the algorithm used in the Rapid is the same as that used for the past 12 years in the LiDCOplus. The difference is that the latter is a calibrated value of the cardiac output whilst the Rapid uses the patient’s height, weight and age to scale the algorithm to produce a nominal cardiac output (nCO). This is then used as a reference pre-induction value in elective patients. Recent work suggests that this monitor is suitable for use for these high-risk patients [58, 59]. The ability of such monitors to obtain a baseline value of the patient’s hemodynamic status prior to induction is an advantage and allows use of the patient as their own control, and the monitors are used to maintain nCO (and therefore oxygen delivery) close to this baseline value throughout surgery. Often there may be a fall in nCO post-induction of up to 50% in elderly patients with limited cardiac reserve . It is clear that hemodynamic monitoring commencing post-induction may greatly underestimate the patient’s starting nCO and nDO2 values, making it impossible to use the patient as their own control. In a study by Lobo et al., patients receiving goal-directed therapy to a target oxygen delivery of 600 ml.min-1.m-2 with dobutamine and fluids using the LiDCOplus with a restricted background infusion of LR of 4 ml.kg-1.hr-1 did better than those receiving the conventional regime of 12 ml.kg-1.hr-1 despite achieving lower goal-directed therapy targets .
What about the role of conventional maintenance fluids given alongside hemodynamic optimization?
The definition of a maintenance fluid in the intraoperative period often confuses basic physiological losses (around 1 to 2 ml.kg-1.hr-1 of crystalloid and around 1 mmol.kg-1 of Na+ per day) with the excess loss due to third-space fluid loss (up to 15 ml.kg-1.hr-1 or 10 mmol.kg-1 Na+ per day). Since third-space loss during elective major surgery is now believed to be minimal [46, 50, 60] (see above), this strategy can result in considerable fluid overload and paradoxically may increase the risk of acute kidney injury in the perioperative period . Elective patients are not usually fluid depleted; any fall in SV during the induction of anesthesia is likely due to alterations in venous capacitance and a fall in venous return and pre-load, making fluid an inappropriate choice of treatment in the early stages of anesthesia.
Any strategy that assumes that this loss still takes place is liable to result in fluid overload and a worsened outcome [48, 49]. Using a stroke volume maximization strategy in patients in a background of excessive DOA again may result in excessive fluid administration. Thus, it would seem rational to base fluid requirement on hemodynamic monitor data with the patient at the optimum depth of anesthesia. In the recently completed Optimise trial the background maintenance fluid was restricted to 1.5ml.kg-1.hr-1. Our own data suggest that optimal hemodynamic targets can be achieved with substantially reduced amounts of Na+ and fluid given (crystalloid maintenance), if hemodynamic monitors are used alongside BIS and a cerebral tissue oximeter .
So, should we be employing a stroke volume maximization strategy?
The stroke volume maximization strategy is based on the false assumption that the Starling curve applies to an intact circulation and that the heart is a driver of tissue oxygenation. The mantra that maximizing CO and DO2 ‘must be good for the patient’ has no sound physiological basis and may be deleterious . In fact, it is the tissues that regulate CO and not the other way round. So, it is probably unnecessary to try to maximize CO and DO2 during major surgery. Maintaining pre-induction DO2 in the intraoperative period seems a more logical strategy. Trying to drive DO2 to a target of 600 ml.min-1.m-2 in an elderly patient with a Hb of 10 g.dl-1 would necessitate a 50% increase in CO to achieve this end point and may impose unnecessary strain on the cardiovascular system. The ability of the tissues to regulate their own blood supply and DO2, especially the brain and muscle, was reviewed by Wolff . A recent Cochrane review suggests that the benefits of a perioperative increase in global blood flow to explicitly defined goals and outcomes following surgery may have been exaggerated .
How do we know that our oxygen delivery is adequate and how do we avoid a build-up of oxygen debt?
As mentioned earlier, it is very easy for oxygen debt to build up during major surgery and lead to postoperative complications. Although postoperative goal-directed therapy aimed at replacing oxygen debt is beneficial , it may not be required if the accumulation of an oxygen debt is kept to a minimum in the first instance. A logical strategy to maintain pre-induction DO2 in elective high-risk patients intraoperatively would be to use pre-induction monitoring. In our institution, for example, this is done by attaining the nCO using a LiDCOrapid monitor slaved off a radial arterial line before induction of anesthesia. During surgery nominal nCO and nominal DO2 (nDO2) are maintained within 10% of pre-induction values. This is achieved by the judicious use of vasopressors such as phenylephrine, commenced pre-induction, to maintain venous tone and venous return combined with fluid challenges, based on stroke volume variation (SVV) whilst ensuring optimal depth of anesthesia . Maintenance of pre-induction values of rSO2 ensures, as best as we can, that oxygen supply/demand and tissue oxygenation are maintained, which may improve outcomes . Falls in rSO2 are corrected by restoration of nCO, nDO2, MAP, oxygen saturation (SpO2) and ensuring normocapnia . If rSO2 continues to fall then it is usually due to blood loss and anemia and is correctable by blood transfusion .
This strategy has given further insights into the problems arising when the blood volume is insufficient to fill the circulatory capacity due to a fall in venous tone. Any discrepancy between blood volume and circulatory capacity will mean there is a reduced blood volume on the arterial/capillary side of the circulation. With the increased capacity due to venodilation on induction there will be a reduction in venous return and thus SV and CO. Those organs with the most robust auto-regulatory capacity (heart and skeletal muscle) will sustain normal blood flow, whereas those with the least will be under-filled. The gut is the first to exhibit a defective blood flow, as suggested by gastric tonometry studies [67, 68]. The next organ is probably the brain, though renal blood flow is also compromised with modest reductions in blood volume (or reduction in the relation of the blood volume to capacity). With careful responses to increased SVV (an indicator of excess venous capacity), there will be a resumption of blood flow to these most vulnerable organs. Some further work is needed to monitor the specific organs during assessment of volume status.
Hemodynamic monitoring commenced pre-induction, together with maintenance of an adequate depth of anesthesia and cerebral oxygenation, helps to ensure intraoperative optimization of oxygen delivery. This not only minimizes or even eliminates any build-up of oxygen debt but also reduces fluid and sodium input, thus allowing true individualization of fluid therapy. Large-scale, prospective randomized trials are urgently needed to prove or disprove that this strategy improves patient outcomes .
Central venous pressure
Depth of anesthesia
Functional extracellular fluid volume
Minimal alveolar concentration
Mean arterial pressure
nominal cardiac output
nominal oxygen delivery
National Institute for Health and Care Excellence
Oesophageal Doppler monitor
Stroke volume variation.
National Institute for Health and Care Excellence:: Medical Technologies Guidance MTG3: CardioQODM Oesophageal Doppler Monitor. 2011, [http://www.nice.org.uk/MTG3]
Association of Anaesthetists of Great Britain and Ireland:: Recommendations for standards of monitoring during anaesthesia and recovery. [http://www.aagbi.org/sites/default/files/standardsofmonitoring07.pdf]
Shoemaker WC, Appel PL, Kram HB: Role of oxygen debt in the development of organ failure sepsis, and death in high-risk surgical patients. Chest. 1992, 102: 208-215. 10.1378/chest.102.1.208.
Shoemaker WC, Appel PL, Kram HB: Hemodynamic and oxygen transport responses in survivors and nonsurvivors of high-risk surgery. Crit Care Med. 1993, 21: 977-990. 10.1097/00003246-199307000-00010.
Gurgel ST, do Nascimento P: Maintaining tissue perfusion in high-risk surgical patients: a systematic review of randomized clinical trials. Anesth Analg. 2011, 112: 1384-1391. 10.1213/ANE.0b013e3182055384.
Hamilton MA, Cecconi M, Rhodes A: A systematic review and meta-analysis on the use of preemptive hemodynamic intervention to improve postoperative outcomes in moderate and high-risk surgical patients. Anesth Analg. 2011, 112: 1392-1402. 10.1213/ANE.0b013e3181eeaae5.
Cannesson M, Pestel G, Ricks C, Hoeft A, Perel A: Hemodynamic monitoring and management in patients undergoing high risk surgery: a survey among North American and European anesthesiologists. Crit Care. 2011, 15: R197-10.1186/cc10364.
Michard F: The burden of high-risk surgery and the potential benefit of goal-directed strategies. Crit Care. 2011, 15: 447-10.1186/cc10473.
Ghosh S, Arthur B, Klein AA: NICE guidance on CardioQ(TM) oesophageal Doppler monitoring. Anaesthesia. 2011, 66: 1081-1083. 10.1111/j.1365-2044.2011.06967.x.
Griffiths R, Alper J, Beckingsale A, Goldhill D, Heyburn G, Holloway J, Leaper E, Parker M, Ridgway S, White S, Wiese M, Wilson I: Management of proximal femoral fractures 2011. Anaesthesia. 2012, 67: 85-98.
Mythen MG, Swart M, Acheson N, Crawford R, Jones K, Kuper M, McGrath JS, Horgan A: Perioperative fluid management: consensus statement from the Enhanced Recovery Partnership. Perioperative Medicine. 2012, 1: 1-4. 10.1186/2047-0525-1-1.
Shepherd J, Jones J, Frampton G, Bryant J, Baxter L, Cooper K: Depth of anaesthesia monitoring (E-entropy, bispectral index and narcotrend). Health Technol Assess. 2012, [http://www.nice.org.uk/dg6]
Green D, Paklet L: Latest developments in peri-operative monitoring of the high-risk major surgery patient. Int J Surg. 2010, 8: 90-99. 10.1016/j.ijsu.2009.12.004.
Scheeren TW, Schober P, Schwarte LA: Monitoring tissue oxygenation by near infrared spectroscopy (NIRS): background and current applications. J Clin Monit Comput. 2012, 26: 279-287. 10.1007/s10877-012-9348-y.
Highton D, Elwell C, Smith M: Noninvasive cerebral oximetry: is there light at the end of the tunnel?. Curr Opin Anaesthesiol. 2010, 23: 576-581. 10.1097/ACO.0b013e32833e1536.
Murkin JM, Arango M: Near-infrared spectroscopy as an index of brain and tissue oxygenation. Br J Anaesth. 2009, 103 (Suppl 1): i3-i13.
Murkin JM, Adams SJ, Novick RJ, Quantz M, Bainbridge D, Iglesias I, Cleland A, Schaefer B, Irwin B, Fox S: Monitoring brain oxygen saturation during coronary bypass surgery: a randomized, prospective study. Anesth Analg. 2007, 104: 51-58. 10.1213/01.ane.0000246814.29362.f4.
Slater JP, Guarino T, Stack J, Vinod K, Bustami RT, Brown JM, Rodriguez AL, Magovern CJ, Zaubler T, Freundlich K, Parr GV: Cerebral oxygen desaturation predicts cognitive decline and longer hospital stay after cardiac surgery. Ann Thorac Surg. 2009, 87: 36-44. 10.1016/j.athoracsur.2008.08.070. discussion 44–45
Casati A, Fanelli G, Pietropaoli P, Proietti R, Tufano R, Danelli G, Fierro G, De Cosmo G, Servillo G: Continuous monitoring of cerebral oxygen saturation in elderly patients undergoing major abdominal surgery minimizes brain exposure to potential hypoxia. Anesth Analg. 2005, 101: 740-747. 10.1213/01.ane.0000166974.96219.cd.
Green DW: A retrospective study of changes in cerebral oxygenation using a cerebral oximeter in older patients undergoing prolonged major abdominal surgery. Eur J Anaesthesiol. 2007, 24: 230-234. 10.1017/S0265021506001645.
Heringlake M, Garbers C, Kabler JH, Anderson I, Heinze H, Schon J, Berger KU, Dibbelt L, Sievers HH, Hanke T: Preoperative cerebral oxygen saturation and clinical outcomes in cardiac surgery. Anesthesiology. 2011, 114: 58-69. 10.1097/ALN.0b013e3181fef34e.
Rifai L, Winters J, Friedman E, Silver MA: Initial description of cerebral oximetry measurement in heart failure patients. Congest Heart Fail. 2012, 18: 85-90. 10.1111/j.1751-7133.2011.00284.x.
Pearse R, Dawson D, Fawcett J, Rhodes A, Grounds RM, Bennett ED: Early goal-directed therapy after major surgery reduces complications and duration of hospital stay. A randomised, controlled trial [ISRCTN38797445]. Crit Care. 2005, 9: R687-R693. 10.1186/cc3887.
Myles PS, Leslie K, McNeil J, Forbes A, Chan MTV, for the B-aware trial group: Bispectral index monitoring to prevent awareness during anaesthesia: the B-Aware randomized controlled trial. Lancet. 2004, 363: 1757-1763. 10.1016/S0140-6736(04)16300-9.
Avidan MS, Jacobsohn E, Glick D, Burnside BA, Zhang L, Villafranca A, Karl L, Kamal S, Torres B, O’Connor M, Evers AS, Gradwohl S, Lin N, Palanca BJ, Mashour GA: Prevention of intraoperative awareness in a high-risk surgical population. N Engl J Med. 2011, 365: 591-600. 10.1056/NEJMoa1100403.
Avidan MS, Zhang L, Burnside BA, Finkel KJ, Searleman AC, Selvidge JA, Saager L, Turner MS, Rao S, Bottros M, Hantler C, Jacobsohn E, Evers AS: Anesthesia awareness and the bispectral index. N Engl J Med. 2008, 358: 1097-1108. 10.1056/NEJMoa0707361.
Chamoun NG: The position of aspect. Anesthesiology. 2000, 92: 897-898.
Punjasawadwong Y, Phongchiewboon A, Bunchungmongkol N: Bispectral Index for Improving Anaesthetic Delivery and Postoperative Recovery, Cochrane Database of Systematic Reviews. 2007, Chichester, UK: Wiley
Monk TG, Saini V, Weldon BC, Sigl JC: Anesthetic management and one-year mortality after noncardiac surgery. Anesth Analg. 2005, 100: 4-10. 10.1213/01.ANE.0000147519.82841.5E.
Kertai MD, Pal N, Palanca BJ, Lin N, Searleman SA, Zhang L, Burnside BA, Finkel KJ, Avidan MS: Association of perioperative risk factors and cumulative duration of low bispectral index with intermediate-term mortality after cardiac surgery in the B-unaware trial. Anesthesiology. 2010, 112: 1116-1127. 10.1097/ALN.0b013e3181d5e0a3.
Leslie K, Myles PS, Forbes A, Chan MT: The effect of bispectral index monitoring on long-term survival in the B-aware trial. Anesth Analg. 2010, 110: 816-822. 10.1213/ANE.0b013e3181c3bfb2.
Lindholm ML, Traff S, Granath F, Greenwald SD, Ekbom A, Lennmarken C, Sandin RH: Mortality within 2 years after surgery in relation to low intraoperative bispectral index values and preexisting malignant disease. Anesth Analg. 2009, 108: 508-512. 10.1213/ane.0b013e31818f603c.
Kertai MD, Palanca BJ, Pal N, Burnside BA, Zhang L, Sadiq F, Finkel KJ, Avidan MS: Bispectral index monitoring, duration of bispectral index below 45, patient risk factors, and intermediate-term mortality after noncardiac surgery in the B-unaware trial. Anesthesiology. 2011, 114: 545-556. 10.1097/ALN.0b013e31820c2b57.
Moller Petrun A, Kamenik M: Bispectral index-guided induction of general anaesthesia in patients undergoing major abdominal surgery using propofol or etomidate: a double-blind, randomized, clinical trial. Br J Anaesth. 2013, 110: 388-396. 10.1093/bja/aes416.
Purushothaman B, O’Brien T, Green DW: The hemodynamic effects of induction and their correlation with changes in depth of anesthesia. ASA Abstracts. 2010, A999-
Mashour GA, Orser BA, Avidan MS: Intraoperative awareness: from neurobiology to clinical practice. Anesthesiology. 2011, 114: 1218-1233. 10.1097/ALN.0b013e31820fc9b6.
Leslie K, Short TG: Low bispectral index values and death: the unresolved causality dilemma. Anesth Analg. 2011, 113: 660-663. 10.1213/ANE.0b013e31822401cc.
Monk TG, Weldon BC: Does depth of anesthesia monitoring improve postoperative outcomes?. Curr Opin Anaesthesiol. 2011, 24: 665-669. 10.1097/ACO.0b013e32834c7acf.
Chan MT, Cheng BC, Lee TM, Gin T: BIS-guided anesthesia decreases postoperative delirium and cognitive decline. J Neurosurg Anesthesiol. 2013, 25: 33-42. 10.1097/ANA.0b013e3182712fba.
Sessler DI, Sigl JC, Kelley SD, Chamoun NG, Manberg PJ, Saager L, Kurz A, Greenwald S: Hospital stay and mortality are increased in patients having a ‘Triple Low’ of low blood pressure, low bispectral index, and low minimum alveolar concentration of volatile anesthesia. Anesthesiology. 2012, 116: 1195-1203. 10.1097/ALN.0b013e31825683dc.
Ballard C, Jones E, Gauge N, Aarsland D, Nilsen OB, Saxby BK, Lowery D, Corbett A, Wesnes K, Katsaiti E, Arden J, Amaoko D, Prophet N, Purushothaman B, Green D: Optimised anaesthesia to reduce post operative cognitive decline (POCD) in older patients undergoing elective surgery, a randomised controlled trial. PLoS One. 2012, 7: e37410-10.1371/journal.pone.0037410.
Steinmetz J, Christensen KB, Lund T, Lohse N, Rasmussen LS: Long-term consequences of postoperative cognitive dysfunction. Anesthesiology. 2009, 110: 548-555. 10.1097/ALN.0b013e318195b569.
Brandstrup B, Tonnesen H, Beier-Holgersen R, Hjortso E, Ording H, Lindorff-Larsen K, Rasmussen MS, Lanng C, Wallin L, Iversen LH, Gramkow CS, Okholm M, Blemmer T, Svendsen PE, Rottensten HH, Thage B, Riis J, Jeppesen IS, Teilum D, Christensen AM, Graungaard B, Pott F: Effects of intravenous fluid restriction on postoperative complications: comparison of two perioperative fluid regimens: a randomized assessor-blinded multicenter trial. Ann Surg. 2003, 238: 641-648. 10.1097/01.sla.0000094387.50865.23.
Nisanevich V, Felsenstein I, Almogy G, Weissman C, Einav S, Matot I: Effect of intraoperative fluid management on outcome after intraabdominal surgery. Anesthesiology. 2005, 103: 25-32. 10.1097/00000542-200507000-00008.
Shires T, Williams J, Brown F: Acute change in extracellular fluids associated with major surgical procedures. Ann Surg. 1961, 154: 803-810. 10.1097/00000658-196111000-00005.
Chappell D, Jacob M, Hofmann-Kiefer K, Conzen P, Rehm M: A rational approach to perioperative fluid management. Anesthesiology. 2008, 109: 723-740. 10.1097/ALN.0b013e3181863117.
Rahbari NN, Zimmermann JB, Schmidt T, Koch M, Weigand MA, Weitz J: Meta-analysis of standard, restrictive and supplemental fluid administration in colorectal surgery. Br J Surg. 2009, 96: 331-341. 10.1002/bjs.6552.
Challand C, Struthers R, Sneyd JR, Erasmus PD, Mellor N, Hosie KB, Minto G: Randomized controlled trial of intraoperative goal-directed fluid therapy in aerobically fit and unfit patients having major colorectal surgery. Br J Anaesth. 2012, 108: 53-62. 10.1093/bja/aer273.
Lobo SM, Ronchi LS, Oliveira NE, Brandao PG, Froes A, Cunrath GS, Nishiyama KG, Netinho JG, Lobo FR: Restrictive strategy of intraoperative fluid maintenance during optimization of oxygen delivery decreases major complications after high-risk surgery. Crit Care. 2011, 15: R226-10.1186/cc10466.
Brandstrup B, Svensen C, Engquist A: Hemorrhage and operation cause a contraction of the extracellular space needing replacement – evidence and implications? A systematic review. Surgery. 2006, 139: 419-432. 10.1016/j.surg.2005.07.035.
Gan TJ, Soppitt A, Maroof M, el-Moalem H, Robertson KM, Moretti E, Dwane P, Glass PS: Goal-directed intraoperative fluid administration reduces length of hospital stay after major surgery. Anesthesiology. 2002, 97: 820-826. 10.1097/00000542-200210000-00012.
Noblett SE, Snowden CP, Shenton BK, Horgan AF: Randomized clinical trial assessing the effect of Doppler-optimized fluid management on outcome after elective colorectal resection. Br J Surg. 2006, 93: 1069-1076. 10.1002/bjs.5454.
Wakeling HG, McFall MR, Jenkins CS, Woods WG, Miles WF, Barclay GR, Fleming SC: Intraoperative oesophageal Doppler guided fluid management shortens postoperative hospital stay after major bowel surgery. Br J Anaesth. 2005, 95: 634-642. 10.1093/bja/aei223.
Brandstrup B, Svendsen PE, Rasmussen M, Belhage B, Rodt SA, Hansen B, Moller DR, Lundbech LB, Andersen N, Berg V, Thomassen N, Andersen ST, Simonsen L: Which goal for fluid therapy during colorectal surgery is followed by the best outcome: near-maximal stroke volume or zero fluid balance?. Br J Anaesth. 2012, 109: 191-199. 10.1093/bja/aes163.
Deltex Medical, Chichester, UK, [http://www.deltexmedical.com/]
Pittman J, Bar-Yosef S, SumPing J, Sherwood M, Mark J: Continuous cardiac output monitoring with pulse contour analysis: a comparison with lithium indicator dilution cardiac output measurement. Crit Care Med. 2005, 33: 2015-2021. 10.1097/01.CCM.0000179021.36805.1F.
Nordstrom J, Hallsjo-Sander C, Shore R, Bjorne H: Stroke volume optimization in elective bowel surgery: a comparison between pulse power wave analysis (LiDCOrapid) and oesophageal Doppler (CardioQ). Br J Anaesth. 2012, 110: 374-380.
Montenij LJ, de Waal EE, Buhre WF: Arterial waveform analysis in anesthesia and critical care. Curr Opin Anaesthesiol. 2011, 24: 651-656.
Mora B, Ince I, Birkenberg B, Skhirtladze K, Pernicka E, Ankersmit HJ, Dworschak M: Validation of cardiac output measurement with the LiDCO(TM) pulse contour system in patients with impaired left ventricular function after cardiac surgery. Anaesthesia. 2011, 66: 675-681. 10.1111/j.1365-2044.2011.06754.x.
Brandstrup B: Fluid therapy for the surgical patient. Best Pract Res Clin Anaesthesiol. 2006, 20: 265-283. 10.1016/j.bpa.2005.10.007.
Prowle JR, Chua HR, Bagshaw SM, Bellomo R: Clinical review: volume of fluid resuscitation and the incidence of acute kidney injury – a systematic review. Crit Care. 2012, 16: 230-10.1186/cc11345.
Optimise trial: [http://www.controlled-trials.com/ISRCTN04386758]
Green DW, Shephard B: Influence of depth of anaesthesia (DOA) and cerebral oximetry (rSO2) monitoring on Na and fluid requirements using the oesophageal Doppler (ODM) for targeted fluid replacement during prolonged major abdominal surgery. ASA Abstracts. 2011, A277-
Wolff CB: Normal cardiac output, oxygen delivery and oxygen extraction. Adv Exp Med Biol. 2007, 599: 169-182. 10.1007/978-0-387-71764-7_23.
Grocott MP, Dushianthan A, Hamilton MA, Mythen MG, Harrison D, Rowan K: Perioperative increase in global blood flow to explicit defined goals and outcomes following surgery. Cochrane Database Syst Rev. 2012, 11: CD004082-
Willars C, Dada A, Hughes T, Green D: Functional haemodynamic monitoring: the value of SVV as measured by the LiDCORapid™ in predicting fluid responsiveness in high risk vascular surgical patients.Int J Surg. 2012, 10: 148-152. 10.1016/j.ijsu.2012.02.003.
Gutierrez G, Brown SD: Gastrointestinal tonometry: a monitor of regional dysoxia. New Horiz. 1996, 4: 413-419.
Mythen MG, Webb AR: Gastrointestinal tonometry comes of age?. Br J Anaesth. 1998, 81: 667-668. 10.1093/bja/81.5.667.
The authors would like to acknowledge the assistance of Dr Christopher Wolff in the writing of this article.
DG has received monitoring equipment on loan and some disposables from Edwards Laboratories, LiDCO PLC, Philips Respironics, Deltex Medical Group and Covidien Inc. He has also received traveling expenses from LiDCO PLC to speak at meetings and he has received honoraria and traveling expenses from Glaxo Smith Kline PLC and Covidien Inc. to speak at meetings. Heena Bidd and Audrey Tan’s research resident posts at King’s College Hospital were partially funded with a £15k annual grant from LiDCO PLC.
All authors contributed equally to writing the review. All authors read and approved the final manuscript.
About this article
Cite this article
Bidd, H., Tan, A. & Green, D. Using bispectral index and cerebral oximetry to guide hemodynamic therapy in high-risk surgical patients. Perioper Med 2, 11 (2013). https://doi.org/10.1186/2047-0525-2-11
- Depth of anesthesia
- Cardiac output monitoring
- Cerebral oximetry
- Triple low
- Intraoperative optimization
- Goal-directed therapy
